RANGER 305D
PRODUCT FEATURES:
• Multi-Process Welding
• Excellent DC multi-process welding for general-purpose stick, downhill pipe (stick), TIG, cored-wire, MIG (CO2 and mixed gas) and arc gouging.
• Only compact diesel welder in North America rated at 29V for 300 amps of stick or CV wire welding.
• CV wire welding with up to 5/64-in. (2.0 mm) diameter electrodes.
• Digital Weld Meters
• Digital weld meters for amps and volts make it easy to precisely pre-set your procedures and monitor actual welding output.
• Superior Arc Performance
• Lincoln Electric Chopper Technology provides easy starts, a smooth arc, low spatter and excellent bead appearance.
• 10,000 Watts Peak Single-Phase AC Generator Power
• 10,000 watts peak for motor starting.
• 9,500 watts continuous for high-capacity needs such as a back-up generator, powering a Lincoln Electric Invertec inverter welder. Also use for lights, a grinder or other power tools.
• AC generator voltage is constant at 120V or 240V at any weld dial setting.
• Skewed Rotor Design
• Skewed rotor design provides AC power suitable for operating Lincoln Electric inverter power sources.
• Rugged Reliability
• Welding and AC generator outputs rated at 104ºF (40ºC).
• 18.8 HP Kubota Diesel Engine
• Water-cooled for low noise
