Allstate Trailer Spares
Bronze Spring Bush 5/8″ x 7/8″ — 2 Pack
Part No: R5613 | Barcode: 9343965003411 | Series: ASTSS Suspension
Sintered bronze spring eye bushes with 5/8″ inner diameter and 7/8″ outer diameter. Sold as a pair, these bushes press into the leaf spring eyes and ride on the shackle bolt, allowing the spring to pivot as it flexes under load.
5/8″ x 7/8″
Bronze
2 Pack
Spring Eye Bush
Suitable For
Leaf Spring Trailers
5/8″ Shackle Bolts
Box Trailers
Boat Trailers
Key Features & Benefits
- Bronze construction — sintered bronze provides excellent wear resistance and self-lubricating properties, reducing maintenance intervals.
- 5/8″ inner diameter — sized to fit 5/8″ shackle bolts (use with R5208 greaseable shackle pins).
- 7/8″ outer diameter — standard press-fit size for most Australian trailer leaf spring eyes.
- Sold as a pair — two bushes per pack for replacing both bushes in one spring eye.
When to Use These Bushes
Replace spring bushes when they become worn, cracked or allow excessive play at the spring eye. The R5613 is the 5/8″ version for heavier-duty springs with larger shackle bolts. Match the inner diameter to your shackle bolt size before ordering.
Authorised Australian Dealer — This product is sourced directly from Allstate Tooling Solutions Australia and is backed by full Australian manufacturer warranty and local support.
Product Specifications
| Part No. | ID x OD | Material | Qty |
|---|---|---|---|
| R5611 | 1/2″ x 7/8″ | Bronze | 2 |
| R5611A | 1/2″ x 7/8″ | Rubber | 2 |
| R5612 | 9/16″ x 7/8″ | Bronze | 2 |
| R5613 ★ | 5/8″ x 7/8″ | Bronze | 2 |
★ You are viewing the highlighted variant.
