Compressed-Air Pressure Gauge — 63mm Dial, Bottom Entry, 1/4″ BSPT (27-06B4-016)
Part No: 27-06B4-016 | Barcode: 21948 | Range: Air Fittings & Piping
The 27-06B4-016 is a dry compressed-air pressure gauge with a 63mm dial face and a bottom entry 1/4″ BSPT connection. Fit it to a compressor, regulator, air receiver or tool manifold to read line pressure at a glance.
63mm Dial
Bottom Entry
1/4″ BSPT
Compressed Air
Dry Gauge
Bourdon Tube
Suitable For
Compressors & Receivers
Air Regulators & FRLs
Air-Tool Manifolds
Workshop Air Reticulation
Key Features & Benefits
- 63mm dial face — clear, easy-to-read scale sized for panel and point-of-use mounting.
- Bottom (base) connection — the 1/4″ BSPT thread enters from the bottom so the gauge sits the right way for direct in-line and stem mounting.
- 1/4″ BSPT thread — taper thread seals on regulators, gauge ports and tee-pieces with thread tape or sealant.
- Bourdon-tube movement — proven mechanical movement for reliable compressed-air pressure indication.
When to Use This Gauge
Reach for part 27-06B4-016 when you need a 63mm gauge with a bottom 1/4″ BSPT port — monitoring compressor, receiver or regulated line pressure. Match the dial size to the space you have and the entry position (rear or bottom) to how the gauge mounts on your regulator, manifold or panel.
Pressure Gauge Range — Sizes Available
| Part No. | Dial | Entry | Thread | Fill |
|---|---|---|---|---|
| 27-04R2-010 | 40mm | Rear Entry | 1/8″ BSPT | Dry |
| 27-04B2-010 | 40mm | Bottom Entry | 1/8″ BSPT | Dry |
| 27-05R4-016B | 50mm | Rear Entry | 1/4″ BSPT | Dry |
| 27-05B4-010 | 50mm | Bottom Entry | 1/4″ BSPT | Dry |
| 27-06R4-016 | 63mm | Rear Entry | 1/4″ BSPT | Dry |
| 27-06B4-016 ★ | 63mm | Bottom Entry | 1/4″ BSPT | Dry |
| 27-L06B4-014 | 63mm | Bottom Entry | 1/4″ BSPT | Liquid Filled |
★ You are viewing the highlighted gauge. Other dial sizes, entry positions and threads in this range are also available.
