Beaver
Beaver Lifting Eye Bolt — Collared 8mm Metric
Part No: 359108 / Barcode: 20981 / Lifting Eye Bolts
The Beaver 359108 Lifting Eye Bolt in 8mm metric thread delivers 0.2t vertical working load capacity. Forged steel construction with an integrated collar provides secure, rated lifting points for machinery, structural steel, and equipment.
WLL 0.2t8mm MetricCollaredAS 2317Forged SteelZinc Dichromate
Suitable For:
Overhead Lifting
Rigging Points
Machinery Installation
Structural Steel
Key Features & Benefits
- Certified 0.2t WLL — Tested and rated to AS 2317 for overhead lifting applications
- Integrated collar — Prevents bolt rotation under angled loads, a critical safety feature for lifting hardware
- Forged steel construction — Consistent grain structure throughout for reliable load-bearing performance
- Zinc dichromate finish — Protective plating resists corrosion in industrial environments
- Metric thread — Standard sizing for compatibility with Australian structural and machinery applications
When to Use This Eye Bolt: Use this 8mm lifting eye bolt to create a permanent rated lifting point at 0.2t capacity. The collar is critical for safety — it prevents the eye bolt from rotating under load, which would dramatically reduce capacity. Torque to specification and inspect regularly per AS 2317 requirements.
Authorised Australian Dealer — This product is sourced directly from Beaver Australia and is backed by full Australian manufacturer warranty and local support.
| Part No. | Thread | WLL |
|---|---|---|
| 359108 ★ | 8mm | 0.2t |
| 359110 | 10mm | 0.3t |
| 359112 | 12mm | 0.5t |
| 359116 | 16mm | 1.0t |
| 359120 | 20mm | 1.5t |
| 359124 | 24mm | 3.0t |
★ You are viewing the highlighted variant. Other sizes in this series are also available.
