Beaver
Beaver G80 Chain Connector 6mm — 1100kg WLL
Part No: C6
Beaver Grade 80 component connector for 6mm chain rated at 1100kg WLL. Consisting of two heavy-duty die-forged halves joined with a stud and pin, this connector provides a secure inline chain connection for lifting assemblies. Compliant with AS 3776.
6mm Chain
1100kg WLL
Grade 80
AS 3776
Die-Forged
Suitable For
Chain Sling Assembly
Lifting Chain
Chain Repair
Key Features & Benefits
- Die-forged construction — two symmetrical halves provide consistent grain flow for maximum strength.
- Heavy-duty stud and pin — secure joining mechanism maintains chain integrity under load.
- Heat-treated alloy steel — Grade 80 rated for certified lifting applications.
- Distinguishing marks — clearly marked for easy identification and chain size matching.
- Replacement pin kits available — serviceable design extends connector life.
When to Use This Chain Connector
The C6 connector joins or extends Grade 80 6mm lifting chain without welding. It assembles inline between chain links using the stud and pin mechanism. Use it for chain sling assembly, field repairs, or when adjusting chain length. The 1100kg WLL rating ensures it matches 6mm G80 chain capacity. Always inspect the pin and stud condition before each use.
Authorised Australian Dealer — This product is sourced directly from Beaver Australia and is backed by full Australian manufacturer warranty and local support.
Product Specifications
| Part No. | Chain Size | WLL |
|---|---|---|
| C6 ★ | 6mm | 1100kg |
| C7-8 | 7–8mm | 2000kg |
| C10 | 10mm | 3200kg |
| C13 | 13mm | 5300kg |
| C16 | 16mm | 8000kg |
| C20 | 20mm | 12500kg |
★ You are viewing the highlighted variant. Other sizes in this series are also available.
