Description
Sutton
Sutton 31/64″ HSS XP Bullet Jobber Drill Bit
Part No: D220H1231 | Barcode: 9311963654676 | Series: D220H XP Bullet
The Sutton D220H1231 is a 31/64″ HSS jobber drill from the XP Bullet range — the upgraded version of the classic Silver Bullet, with an extreme parabolic flute (XP) profile that pulls chips out of the cut faster and a 135° split point that eliminates centre-punching. M2 high-speed steel for general engineering work in steel, aluminium, brass, wood, and plastics.
31/64″ Diameter
M2 High Speed Steel
XP Parabolic Flute
135° Split Point
Self-Centring
Bright Finish
DIN 338 Length
Suitable For
Mild Steel
Aluminium
Brass & Copper
Cast Iron
Wood
Plastics
General-Purpose Drilling
Key Features & Benefits
- XP (extreme parabolic) flute — the deeper, wider flute geometry pulls swarf out of the hole faster than a conventional jobber, reducing chip packing and bit overheating in deep holes. Particularly noticeable in aluminium and free-cutting steel where chips would otherwise bind.
- 135° split point — self-centring on smooth surfaces; no centre punch needed. Cuts the workpiece preparation step out of repetitive drilling jobs.
- M2 high-speed steel — standard tough tool steel for general engineering. Holds an edge through repeated drilling without backing off; resharpens easily on a standard drill grinder.
- Reduced thrust force — the split point and parabolic flute together reduce the push pressure needed to start and continue the cut. Important for hand-held cordless drilling where the operator gets fatigued and starts deflecting the drill.
- Precision parallel shank — the shank runs to the same diameter tolerance as the cutting flutes, so the drill runs true in any 3-jaw chuck without wobble.
- DIN 338 jobber length — matches metric jobber standards exactly, fitting any drill index, depth gauge, or collet system designed for jobber-length drills.
When to Use This Drill
The Sutton D220H1231 (31/64″ XP Bullet) is the upgraded everyday jobber drill — the right choice for general drilling in mild steel, aluminium, plastics, timber, and softer cast iron where the parabolic flute and split point reduce drilling effort. For stainless steel and hardened alloys, step up to the D108 cobalt range; for ultra-precision work needing tight diameter tolerance, use the D101 Silver Bullet metric range. For impact driver use, switch to the D213 Supabit hex shank.
Pro Tip: XP Bullet drills run faster than conventional jobbers because of the lower thrust requirement — if you’re used to standard HSS drills, your usual feed pressure will be too heavy. Let the drill pull itself into the work; firm pressure but not heavy. The 135° split point starts so easily that walking is rarely an issue, but the bit will skate up wear ramps if you’re drilling near an existing hole or edge. Square the work first.
Authorised Sutton Dealer — Sutton Tools is an Australian-owned manufacturer (Thomastown, Victoria). This product is backed by full Sutton manufacturer warranty with local technical support — visit Sutton Tools for the full D220H XP Bullet range.
Product Specifications
| Part No. | Diameter |
|---|---|
| D220H0100 | 1.0mm |
| D220H0150 | 1.5mm |
| D220H0159 | 1/16″ |
| D220H0198 | 5/64″ |
| D220H0200 | 2.0mm |
| D220H0238 | 3/32″ |
| D220H0250 | 2.5mm |
| D220H0278 | 7/64″ |
| D220H0300 | 3.0mm |
| D220H0318 | 1/8″ |
| D220H0350 | 3.5mm |
| D220H0357 | 9/64″ |
| D220H0397 | 5/32″ |
| D220H0400 | 4.0mm |
| D220H0437 | 11/64″ |
| D220H0450 | 4.5mm |
| D220H0476 | 3/16″ |
| D220H0500 | 5.0mm |
| D220H0516 | 13/64″ |
| D220H0550 | 5.5mm |
| D220H0556 | 7/32″ |
| D220H0595 | 15/64″ |
| D220H0600 | 6.0mm |
| D220H0635 | 1/4″ |
| D220H0650 | 6.5mm |
| D220H0676 | 17/64″ |
| D220H0700 | 7.0mm |
| D220H0714 | 9/32″ |
| D220H0750 | 7.5mm |
| D220H0794 | 5/16″ |
| D220H0833 | 21/64″ |
| D220H0850 | 8.5mm |
| D220H0873 | 11/32″ |
| D220H0900 | 9.0mm |
| D220H0913 | 23/64″ |
| D220H0950 | 9.5mm |
| D220H0953 | 3/8″ |
| D220H0992 | 25/64″ |
| D220H1000 | 10.0mm |
| D220H1072 | 27/64″ |
| D220H1100 | 11.0mm |
| D220H1111 | 7/16″ |
| D220H1150 | 11.5mm |
| D220H1151 | 29/64″ |
| D220H1191 | 15/32″ |
| D220H1200 | 12.0mm |
| D220H1231 ★ | 31/64″ |
| D220H1250 | 12.5mm |
| D220H1269 | 1/2″ |
| D220H1300 | 13.0mm |
★ You are viewing the highlighted size. Other sizes in the D220H XP Bullet range are also available — click any part number above.
Browse our full range of drill bits at Alltools Geelong.
