Description
Sutton D604T0600 — masonry/tile drill available at Alltools Geelong. Shop our full masonry/tile drill range in Geelong.
Sutton
Sutton 6.0 Glass & Tile Drill Bit
Part No: D604T0600 | Barcode: 9311963657974 | Series: Glass/Tile 5pk
The Sutton D604T0600 is a glass and tile drill, 6.0 arrow-tipped tungsten carbide bit designed for drilling through glazed surfaces — tile, ceramic, porcelain, and glass — without cracking the surface or running off centre. Different geometry to a masonry drill: the tip is ground sharp, not blunt, so it cuts cleanly rather than hammering.
6.0mm
85mm Long
Tungsten Carbide Tip
Arrow-Tip Geometry
Glazed Surface Specialist
Suitable For
Glazed Ceramic Tile
Porcelain Tile
Glass
Mirror
Marble
Bathroom Wall Tile
Key Features & Benefits
- Arrow-tip carbide point — ground to a sharp angle (not the blunt percussion tip used on masonry bits) so it scrapes the glaze cleanly rather than hammering and cracking it.
- Designed for rotary mode only — never use hammer action on glazed tile; the impact will craze or fracture the surface around the hole.
- Carbide cutting edge — cuts through glass and ceramic without losing the edge, where HSS drills go blunt in the first hole.
- Slow speed, water-cooled work — ideal for bathroom retrofits, kitchen splashbacks, and any tile work where the back of the substrate (plasterboard, masonry) needs different drilling.
When to Use This Drill
The Sutton D604T0600 (6.0 glass/tile) is the right tool for any glazed surface — bathroom tile, kitchen splashback, ceramic floor work, porcelain, and glass. Run in rotary mode only. For the masonry behind the tile, switch to a TCT masonry drill in the same size.
Pro Tip: Apply masking tape to the tile face before drilling — the tape gives the bit something to bite without skating across the glaze, and protects the surrounding tile from accidental scratches. Run the drill in rotary mode only at low to medium RPM (~600-800), with light pressure and a wet sponge or constant water trickle to keep the carbide tip cool. The hole will take longer than masonry but will come out clean.
Authorised Sutton Dealer — Sutton Tools is an Australian-owned manufacturer (Thomastown, Victoria). This product is backed by full Sutton manufacturer warranty with local technical support — visit Sutton Tools for the full masonry & tile range.
Product Specifications
| Part No. | Type | Diameter | Length |
|---|---|---|---|
| D6000300 | TCT Masonry | 3.0mm | 60mm |
| D6000400 | TCT Masonry | 4.0mm | 75mm |
| D6000500 | TCT Masonry | 5.0mm | 85mm |
| D6000550 | TCT Masonry | 5.5mm | 85mm |
| D6000600 | TCT Masonry | 6.0mm | 100mm |
| D6000650 | TCT Masonry | 6.5mm | 100mm |
| D6000700 | TCT Masonry | 7.0mm | 100mm |
| D6000800 | TCT Masonry | 8.0mm | 120mm |
| D6001000 | TCT Masonry | 10.0mm | 120mm |
| D6011000 | TCT Masonry Long | 10.0mm | 150mm |
| D6011100 | TCT Masonry Long | 11.0mm | 150mm |
| D6011200 | TCT Masonry Long | 12.0mm | 150mm |
| D6011300 | TCT Masonry Long | 13.0mm | 150mm |
| D6011400 | TCT Masonry Long | 14.0mm | 150mm |
| D6011600 | TCT Masonry Long | 16.0mm | 150mm |
| D6040600 | Glass & Tile | 6.0mm | 85mm |
| D604T0600 ★ | Glass/Tile 5pk | 6.0mm | 85mm |
| D604S05A | Glass/Tile Set | 4-8mm Set | 5pc |
★ You are viewing the highlighted variant. Other masonry and tile drills are also available — click any part number above.
Browse our full range of drill bits at Alltools Geelong.
