Harlingen H-11-047-T006 4-Flute End Mill — 8mm, HSS TiN-Coated
Part No: H-11-047-T006 | Barcode: H-11-047-T006
The Harlingen H-11-047-T006 is a 8mm four-flute HSS end mill with a wear-resistant TiN coating. Centre-cutting with a Weldon shank to DIN 844, it suits side milling, profiling and finishing passes in steel, cast iron and non-ferrous metals.
8mm Cutting Dia
4 Flutes
HSS
TiN-Coated
Weldon Shank
DIN 844
Centre-Cutting
Suitable For
Steel
Cast Iron
Non-Ferrous Metals
Key Features & Benefits
- 4-flute design — more cutting edges give a smoother finish and support higher feed rates on side milling and profiling.
- TiN coating — reduces friction and wear for longer tool life and faster cutting speeds.
- Weldon flatted shank — locks securely in a side-lock holder with no slip under load.
- Centre-cutting, DIN 844 — standardised geometry that drops straight into common collets and holders.
When to Use This Tool
Choose the H-11-047-T006 for side milling, contouring and finishing where surface finish matters. For full-width slotting or plunging, a 2-flute end mill clears chips better.
Pro Tip: Four-flute end mills don’t plunge well — ramp in or pre-drill a starter hole rather than plunging straight down to protect the centre.
Authorised Australian Dealer — This product is sourced from Gamer Australia and is backed by full Australian supplier warranty and local support.
Product Specifications
| Part No. | Cutting Dia. | Length | Flutes |
|---|---|---|---|
| H-11-047-T001 | 3mm | Standard | 4 |
| H-11-047-T002 | 4mm | Standard | 4 |
| H-11-047-T003 | 5mm | Standard | 4 |
| H-11-047-T004 | 6mm | Standard | 4 |
| H-11-047-T006 ★ | 8mm | Standard | 4 |
| H-11-047-T008 | 10mm | Standard | 4 |
| H-11-047-T010 | 12mm | Standard | 4 |
| H-11-047-T011 | 14mm | Standard | 4 |
| H-11-047-T012 | 16mm | Standard | 4 |
| H-11-047-T014 | 20mm | Standard | 4 |
★ You are viewing the highlighted variant. Other sizes in this range are also available.
Browse our full range of end mills at Alltools Geelong.
