Harlingen MT4 High-Precision Live Centre — H-41-323-004
Part No: H-41-323-004 | Barcode: 9346967110644 | Brand: Harlingen
A precision Morse Taper 4 live centre with sealed bearings, 0.005mm runout, 3800 RPM rated speed and an 800kg maximum workpiece load. Built for tailstock support on lathes with an MT4 tailstock socket.
MT4 Taper
0.005mm Runout
3800 RPM Max
800 kg Load
Sealed Bearings
Hardened Steel
Compatible Materials
Hardened Tool Steel
Key Features & Benefits
- Morse Taper 4 (MT4) shank — Self-holding taper drives directly into MT4 tailstock sockets without an adaptor sleeve.
- 0.005 mm runout accuracy — Fine-finish turning, threading and grinding work stays concentric end-to-end.
- Rated to 3800 RPM — Sealed bearings handle higher tailstock speeds than a plain dead centre allows.
- 800 kg maximum workpiece load — Suits long, heavy shafts where a smaller MT2 or MT3 centre would deflect.
- Sealed bearing pack — Keeps swarf and coolant out, extending life in production environments without re-greasing.
When to Use This Tool
Reach for H-41-323-004 when your lathe has an MT4 tailstock and you’re turning, threading or grinding shafts that need rotating support. The 800 kg capacity makes it appropriate for medium-to-large engine lathes and CNC turning centres.
Authorised Australian Distributor — This product is sourced via Australia’s Harlingen distributor Gamer Industries and is backed by full Australian warranty and local support.
Product Specifications
| Part No. | Taper | Max RPM | Max Load | Runout |
|---|---|---|---|---|
| H-41-323-002 | MT2 | — | — | 0.005 mm |
| H-41-323-003 | MT3 | 5000 RPM | 500 kg | 0.005 mm |
| H-41-323-004 ★ | MT4 | 3800 RPM | 800 kg | 0.005 mm |
| H-41-323-005 | MT5 | — | — | 0.005 mm |
| H-41-323-006 | MT6 | — | — | 0.005 mm |
★ You are viewing the highlighted variant. Other sizes in this series are also available.
Browse our full range of lathe centres at Alltools Geelong.
