Milwaukee
M12BCST-0 12V Cable Stapler — 25mm Insulated Staples
Part No: M12BCST-0 | Barcode: 4892210207920
The Milwaukee M12BCST-0 is a 12V cordless cable stapler designed to secure NM-B sheathed cable and low-voltage wiring with 25mm insulated staples. Its coil-spring mechanism ensures consistent staple depth across every fastening, completing rough-ins twice as fast as manual hammer stapling.
12V M12
25mm (1″) Insulated Staples
45 Staple Magazine
1,200 Staples Per Charge
Dry Fire Lock Out
2.4 kg
Suitable Applications
NM-B Sheathed Cable
Low Voltage Cable
Data Cable
Electrical Rough-In
Timber Framing
Key Features & Benefits
- Coil-spring mechanism for consistent staple depth — drives every staple to the same depth, preventing cable damage from over-driven staples.
- 1,200 staples per charge on M12 CP2.0 battery — handles multiple room rough-ins on a single charge without battery swaps.
- 45-staple magazine capacity — reduces reload frequency during production cable runs.
- Dry fire lock out — prevents firing when the magazine is empty, protecting both the tool and the work surface.
- Moveable cable guides — centre the cable under the staple for secure, damage-free fastening regardless of cable diameter.
- Staple viewing window — shows remaining staple count at a glance without opening the magazine.
- Two-finger trigger with LED work light — provides controlled firing and illumination in dark stud cavities.
- Reversible belt hook and battery fuel gauge — convenient holstering for left or right-handed users with at-a-glance charge status.
When to Use This Stapler
Choose the M12BCST-0 for electrical rough-in work where NM-B sheathed cable or low-voltage wiring needs to be secured to timber studs and joists. This tool is ideal for electricians and data cablers who install hundreds of cable staples per day — it eliminates the repetitive hammering that causes wrist fatigue and inconsistent staple depth. The consistent coil-spring mechanism prevents cable damage from over-driven staples, which is critical for passing electrical inspections. Uses Milwaukee 25mm (1″) insulated cable staples sold separately. Skin only — battery and charger sold separately.
Pro Tip: Keep the cable guides adjusted to match your cable diameter before starting a run. This centres the staple over the cable and prevents the staple legs from pinching or nicking the cable jacket.
Authorised Australian Dealer — This product is sourced directly from Milwaukee Australia and is backed by full Australian manufacturer warranty and local support.
Product Specifications
| Part No. | Voltage | Staple Size | Magazine Capacity | Staples Per Charge | Dimensions L×W×H (mm) | Weight (kg) | Barcode |
|---|---|---|---|---|---|---|---|
| M12BCST-0 ★ | 12V | 25mm (1″) Insulated | 45 | 1,200 | 165 × 67 × 294 | 2.4 | 4892210207920 |
★ You are viewing the highlighted variant.
