Milwaukee
M12 FUEL Gen 3 13 mm Hammer Drill Driver — 45 Nm, Ultra-Compact 152 mm
Part No: M12FPD2-0 | Barcode: 4892210209764
Milwaukee’s M12FPD2-0 is the Gen 3 M12 FUEL 13 mm hammer drill driver, delivering 45 Nm of torque with a POWERSTATE brushless motor in a body just 152 mm long. Thirteen clutch settings and 22,500 BPM hammer action make it a genuine subcompact workhorse for trades who need full hammer drill capability in a 12V form factor.
45 Nm Torque
22,500 BPM
1,550 RPM
13 mm Metal Chuck
152 mm Length
13 Clutch Settings
12V M12 Platform
Suitable For
Light Masonry
Timber
Steel
Plasterboard
Overhead Work
Tight Spaces
Key Features & Benefits
- POWERSTATE Brushless Motor — delivers 45 Nm of torque and 1,550 RPM from a compact brushless motor that runs cooler and lasts longer than brushed alternatives.
- Ultra-Compact 152 mm Length — fits into ceiling cavities, between studs, and inside electrical enclosures where 18V drills are too bulky to manoeuvre.
- 13 mm Heavy-Duty Metal Chuck — grips standard round-shank and hex bits up to 13 mm securely, matching the capacity of full-size 18V drills.
- 13 Clutch Settings + Drill + Hammer — fine torque control for precision screw driving plus full hammer mode for masonry fixings in brick and block.
- 22,500 BPM Hammer Action — genuine percussion drilling for light masonry anchors and fixings without needing a separate SDS hammer.
- REDLINK PLUS Intelligence — real-time communication between tool and battery prevents overload, overheating, and over-discharge.
When to Use This Compact Hammer Drill
The M12FPD2-0 is the hammer drill for trades who need 13 mm chuck capacity and hammer action in the lightest, most compact package possible. Electricians, data cablers, and HVAC installers carry it as their primary drill for overhead work, ceiling cavity access, and tight switchboard enclosures. The 45 Nm output handles most general drilling and driving tasks — only step up to an 18V platform when you need sustained heavy-duty drilling in hardwood or dense masonry. At 152 mm and well under 1.5 kg with battery, it is the drill you forget you are carrying until you need it.
Authorised Australian Dealer — This product is sourced directly from Milwaukee Tool Australia and is backed by full Australian manufacturer warranty and local support.
Product Specifications
| Specification | Value |
|---|---|
| Voltage | 12V |
| Max Torque | 45 Nm |
| No-Load Speed | 0–1,550 RPM |
| Impact Rate | 0–22,500 BPM |
| Chuck | 13 mm Heavy-Duty Metal |
| Clutch Settings | 13 + Drill + Hammer |
| Body Length | 152 mm |
| Weight (bare) | ~1.0 kg |
| Motor | POWERSTATE Brushless |
| Battery Platform | M12 REDLITHIUM |
| Warranty | 5 Years |
