SOLA
SOLA RED 3 Spirit Level — 200 cm Box Profile
Part No: RED3200 | Barcode: 45605 | Length: 2000 mm
The SOLA RED 3 is a professional-grade Austrian-made box-profile spirit level built for daily site use. The 200 cm (2000 mm) variant carries three FOCUS magnification vials in an extra-strong red-coated aluminium profile, delivering 0.30 mm/m accuracy in standard position and 0.50 mm/m inverted.
200 cm Length
3 Vials (1H + 2V)
0.30 mm/m Accuracy
FOCUS Magnification +60%
59 x 27 mm Profile
Made in Austria
Key Features & Benefits
- SOLA FOCUS vials — integrated +60% magnification lens makes the bubble dramatically easier to read at arm’s length, on dim job sites, or from awkward angles.
- 0.30 mm/m measuring accuracy — standard position tolerance of 0.017° (and 0.029° inverted) hits the precision required for cabinetry, tile setting, frame work and machine alignment.
- Extra-strong 59 x 27 mm aluminium box profile — reinforcing internal ribs resist twist and bow, so the level stays true after the inevitable knocks and drops.
- Acrylic block vials with 30-year leakage guarantee — the unbreakable solid-block construction shrugs off impacts that destroy ordinary glass-tube vials.
- Two-component shock-absorbing end caps — protect both the profile and the vials when the level is set down hard or dropped on its end.
- Optimised SOLA light plate background — high-contrast yellow backing keeps the bubble visible in twilight, basement work and dim interiors.
- Wear-resistant powder-coated measuring face — the red epoxy coating shields the milled aluminium reference edge from job-site abrasion.
When to use the RED3200: the 200 cm RED 3 suits long-run masonry, floor screeding, brick courses and structural alignment where a single uninterrupted reference is essential. Choose a shorter RED 3 (60 or 80 cm) for joinery and door work, or a longer 180–240 cm RED 3 if you regularly span window/door openings or full-height walls in one shot.
Pro Tip: The RED 3 is rated for inverted measurement (0.50 mm/m) as well as standard, so trust the bubble when you flip the level overhead for ceiling battens, soffit lines or under-bench rails — you do not need to remeasure from a different reference. Re-check the calibration by laying the level on a known-flat surface, marking the bubble, then rotating end-for-end — the bubble should sit identically on the second reading.
Product Specifications
| Part No. | Length | Profile | Vials | Accuracy (Normal) | Accuracy (Overhead) |
|---|---|---|---|---|---|
| RED040 | 40cm (400mm) | 59 × 27 mm | 1H / 2V | 0.30 mm/m (0.017°) | 0.50 mm/m (0.029°) |
| RED3060 | 60cm (600mm) | 59 × 27 mm | 1H / 2V | 0.30 mm/m (0.017°) | 0.50 mm/m (0.029°) |
| RED3080 | 80cm (800mm) | 59 × 27 mm | 1H / 2V | 0.30 mm/m (0.017°) | 0.50 mm/m (0.029°) |
| RED3120 | 120cm (1200mm) | 59 × 27 mm | 1H / 2V | 0.30 mm/m (0.017°) | 0.50 mm/m (0.029°) |
| RED3200 ★ | 200cm (2000mm) | 59 × 27 mm | 1H / 2V | 0.30 mm/m (0.017°) | 0.50 mm/m (0.029°) |
★ You are viewing the highlighted variant. Other lengths in the RED 3 series are also available.
Browse our full range of spirit levels at Alltools Geelong.
