Sutton P&N Workshop Double-Ended Panel Drill — #30 (3.26 mm)
Part No: 165611285 | Barcode: 9311744442461 | Series: P&N Workshop TiN-Coated
Note: Sold individually — price is per drill, not per pack.
Sutton P&N Workshop 165611285 is a #30 (3.26 mm) double-ended panel drill, HSS with a Titanium Nitride (TiN) coating for up to 3× longer life. 135° self-centring tip and 54 mm overall — built for high-volume drilling of 1/8″ pop-rivet holes in flat and curved sheet panels. Two cutting tips per drill for extended life on long sheet-metal runs.
#30 (3.26 mm)
Double-Ended
HSS-TiN Coated
135° Self-Centring
54 mm OAL
19 mm Flute
Compatible Materials
Mild Steel Sheet
Aluminium Panel
Galvanised Steel
Stainless Sheet
Key Features & Benefits
- TiN coating — Titanium Nitride surface increases wear resistance and delivers up to 3× the tool life of an uncoated HSS panel drill in the same job.
- Double-ended design — two cutting tips per drill, doubling tool life and cutting changeover time on long sheet-metal runs.
- 135° self-centring tip — starts the hole exactly where the bit is placed, no centre punch needed on flat or curved panel.
- Short 19 mm flute — optimised for shallow holes (no deeper than 1.25× diameter) so the drill stays rigid on thin material.
- Sized for 1/8″ pop rivets — #30 wire gauge is the standard hole size for blind rivets used across automotive, trailer, caravan and aircraft panel work.
When to Use This Drill
Choose Sutton P&N 165611285 when you’re drilling long runs of #30 rivet holes and want the extra tool life that TiN coating gives you over plain bright-finish HSS. Best for repetition work in workshops doing automotive, trailer, RV or sheet-metal fabrication. For one-off jobs the bright-finish D122 Silver Bullet is more economical; step up to TiN when volume justifies the cost.
Pro Tip: TiN coating works best with a lighter feed pressure than bare HSS — let the coating do the cutting. Push too hard and you’ll break through the coating prematurely on the first dozen holes; light, steady pressure at moderate speed (around 2000 rpm in steel sheet) is what gets you the 3× life.
Authorised Australian Dealer — This product is sourced directly from Sutton Tools Australia and is backed by full Australian manufacturer warranty and local support.
Product Specifications
| Part No. | Wire | Diameter (mm) | Overall Length | Flute Length | Coating |
|---|---|---|---|---|---|
| 165611285 ★ | #30 | 3.26 | 54 mm | 19 mm | HSS-TiN |
★ You are viewing the highlighted variant. Other Sutton TuPoint and Workshop panel drills are also available in the same #11 / #20 / #30 / 1/8″ sizes.
