Description
Sutton
Sutton TuPoint Double-Ended Panel Drill — #30 (3.26 mm)
Part No: 9D30 | Barcode: 9342386009019 | Series: D122 Silver Bullet
Note: Sold individually — price is per drill, not per pack.
Sutton 9D30 is a #30 (3.26 mm) double-ended TuPoint panel drill from the D122 Silver Bullet range — M2 HSS, 135° self-centring split point, and a short 19 mm flute optimised for shallow holes in flat and curved sheet panels. The double-ended geometry gives you two cutting tips per drill for high-volume rivet-hole and sheet-metal work.
#30 (3.26 mm)
Double-Ended
M2 HSS
135° TuPoint
54 mm OAL
Compatible Materials
Mild Steel Sheet
Aluminium Panel
Galvanised Steel
Non-Ferrous Metals
Key Features & Benefits
- Double-ended design — two cutting ends per drill, effectively doubling the working life of every bit and halving the changeover cost on long production runs.
- 135° TuPoint split point — self-centres on contact so there’s no walking, no centre-punching, and no pilot drilling on flat or curved sheet stock.
- Short flute, 54 mm overall — extra rigidity for shallow panel-depth holes (max ~1.25× diameter) which means less breakage when the drill snatches on thin sheet.
- M2 high-speed steel — the same alloy Sutton uses across the Silver Bullet range; balanced strength, heat resistance and edge life for repetition drilling.
- Bright finish — clean, low-friction surface for general-purpose ferrous and non-ferrous panel work.
When to Use This Drill
Choose Sutton 9D30 for sheet-metal fabrication, panel beating, automotive body and trailer work where you’re drilling lots of #30 holes through thin material. Sized to drill clean, accurate holes for 1/8″ pop rivets. If you need a longer reach for jobber-depth holes, step up to a standard jobber drill — TuPoint is purpose-built for short, repetitive panel-depth work.
Pro Tip: Run these on a low-mid speed (around 1500–2500 rpm in mild steel sheet) with steady, light pressure — the 135° split point self-starts without a centre punch, which is what makes the TuPoint geometry so fast on repetitive panel work.
Authorised Australian Dealer — This product is sourced directly from Sutton Tools Australia and is backed by full Australian manufacturer warranty and local support.
Product Specifications
| Part No. | Wire / Imperial | Diameter (mm) | Overall Length |
|---|---|---|---|
| D1220318 | 1/8″ | 3.18 | 54 mm |
| D1220326 | #30 | 3.26 | 54 mm |
| D1220409 | #20 | 4.09 | 54 mm |
| D1220485 | #11 | 4.85 | 54 mm |
| 9D30 ★ | #30 (carded) | 3.26 | 54 mm |
★ You are viewing the highlighted variant. Other sizes in the D122 TuPoint range are also available.
Browse our full range of panel drill bits at Alltools Geelong.
