Beaver Grade S Yellow Pin Dee Shackle — 13 x 16mm
Part No: 241313 / Barcode: 34732 / Grade S Dee Shackles
The Beaver 241-series Grade S Dee Shackle in 13 x 16mm delivers a 2.0t working load limit for demanding lifting, rigging, and towing applications. Hot dipped galvanised body with a distinctive yellow screw pin makes it easy to identify rated hardware on site.
WLL 2.0tSize 13 x 16mmGrade SAS 2741Hot Dipped GalvYellow Screw Pin
Suitable For:
Lifting
Rigging
Towing
4WD Recovery
Mining
Construction
Key Features & Benefits
- Grade S rated — High-strength forged steel construction tested and certified to AS 2741 for overhead lifting
- Yellow screw pin — Painted pin allows quick visual identification of rated shackles versus commercial grade
- Hot dipped galvanised — Corrosion-resistant finish suitable for outdoor and marine-adjacent environments
- Dee shape profile — Provides a narrow, inline connection ideal for single-leg sling attachments and chain terminations
- Screw pin closure — Easy to install and remove by hand for frequent rigging changes
When to Use This Shackle: Choose this 13 x 16mm Grade S dee shackle for overhead lifting applications requiring up to 2.0t capacity. The dee shape suits single-direction loads and inline chain or wire rope terminations. For multi-directional or side-loaded connections, consider a bow shackle instead.
Authorised Australian Dealer — This product is sourced directly from Beaver Australia and is backed by full Australian manufacturer warranty and local support.
| Part No. | Size (mm) | WLL |
|---|---|---|
| 241306 | 6 x 8mm | 0.5t |
| 241308 | 8 x 10mm | 0.75t |
| 241310 | 10 x 11mm | 1.0t |
| 241311 | 11 x 13mm | 1.5t |
| 241313 ★ | 13 x 16mm | 2.0t |
| 241316 | 16 x 19mm | 3.2t |
| 241319 | 19 x 22mm | 4.7t |
| 241322 | 22 x 25mm | 6.5t |
| 241325 | 25 x 29mm | 8.5t |
| 241329 | 29 x 32mm | 9.5t |
| 241332 | 32 x 35mm | 12.0t |
| 241335 | 35 x 38mm | 13.5t |
| 241338 | 38 x 41mm | 17.0t |
| 241344 | 44 x 51mm | 25.0t |
| 241351 | 51 x 57mm | 35.0t |
★ You are viewing the highlighted variant. Other sizes in this series are also available.
