Beaver
Beaver 3S Lever Block 500kg — Grey
Part No: 506050
Beaver 3S lever block rated at 500kg with 1.5m standard lift height. Compact and versatile design for lifting, pulling, and tensioning applications. Built with G80 calibrated load chain and tested to AS 1418.2.
500kg WLL
1.5m Lift
G80 Chain
AS 1418.2
2.5kg
Grey Coded
Suitable For
Lifting
Pulling
Tensioning
Rigging
Construction
Key Features & Benefits
- G80 zinc-plated load chain — calibrated to ISO 3077 and ISO 1834 for consistent performance and corrosion resistance.
- Compact design — lightweight at 2.5kg for easy handling in confined spaces and overhead work.
- Lifting and pulling — versatile lever action suits horizontal pulling and tensioning as well as vertical lifting.
- Stainless steel ID plates — spark-resistant identification suitable for mining environments.
- Individual test certificates — each unit operationally tested to rated capacity with full documentation.
- International colour coding — Grey for quick 500kg WLL identification.
When to Use This Lever Block
The 506050 lever block is rated at 500kg with 320N effort required at full load. Lever blocks excel where chain blocks cannot reach — horizontal pulling, angled tensioning, and confined space lifting. The lever mechanism provides precise load control without needing overhead mounting. Choose this capacity for loads up to 500kg.
Authorised Australian Dealer — This product is sourced directly from Beaver Australia and is backed by full Australian manufacturer warranty and local support.
Product Specifications
| Part No. | Capacity | Lift Height | Effort |
|---|---|---|---|
| 506025 | 250kg | 1.5m | 210N |
| 506050 ★ | 500kg | 1.5m | 320N |
| 506080 | 800kg | 1.5m | 140N |
| 506160 | 1600kg | 1.5m | 240N |
| 506320 | 3200kg | 1.5m | 320N |
| 506630 | 6300kg | 1.5m | 340N |
★ You are viewing the highlighted variant. Other capacities in this series are also available.
