TOOLMASTER
4 Jaw Independent Lathe Chuck — K72-100, Ø100mm Back Plate Mount
Part No: C230 | Barcode: 9344195012488 | Model: K72-100
TOOLMASTER K72-100 4 Jaw Independent Lathe Chuck (Ø100mm Back Plate Mount). Manufactured from High Strength semi steel and precision machined Jaws are case-hardened to minimise wear Operating screws are made from alloy steel and case-hardened
Model K72-100
Ø100mm
Back Plate Mount
Speed: 3500 rpm
Key Features & Benefits
- Rear Mounting
About This Product
Manufactured from High Strength semi steel and precision machined Jaws are case-hardened to minimise wear Operating screws are made from alloy steel and case-hardened This is a Hare & Forbes special-order item, available to order through Alltools Geelong (order code C230) for collection in store.
Product Specifications
| Specification | Detail |
|---|---|
| Chuck Size | Ø100 |
| External Jaw Range (mm) | 40 – 100 |
| Internal Jaw Range (mm) | 6 – 45 |
| Speed (rpm) | 3500 |
| D1 (mm) | 72 |
| D2 (mm) | 84 |
| D3 (mm) | 25 |
| H1 (mm) | 54 |
| h (mm) | 4 |
| z-d (mm) | 4 – M8 |
| Nett Weight (kg) | 3.2 |
