TOOLMASTER
4 Jaw Independent Lathe Chuck — K72-320/D1-8, Ø320mm D1-8 Camlock Mount
Part No: C256A | Barcode: 9344195012549 | Model: K72-320/D1-8
TOOLMASTER K72-320/D1-8 4 Jaw Independent Lathe Chuck (Ø320mm D1-8 Camlock Mount). Manufactured from High Strength semi steel and precision machined Jaws are case-hardened to minimise wear Operating screws are made from alloy steel and case-hardened. Supplied with camlock pins, 1 set of jaws and wrench.
Model K72-320/D1-8
Ø320mm
D1-8 Camlock Mount
Speed: 1200 rpm
About This Product
Manufactured from High Strength semi steel and precision machined Jaws are case-hardened to minimise wear Operating screws are made from alloy steel and case-hardened. Supplied with camlock pins, 1 set of jaws and wrench. This is a Hare & Forbes special-order item, available to order through Alltools Geelong (order code C256A) for collection in store.
Product Specifications
| Specification | Detail |
|---|---|
| Chuck Size (mm) | Ø320 |
| Camlock | D1-8 |
| Speed (rpm) | 1200 |
| D1 (mm) | 139.7 |
| D2 (mm) | 171.4 |
| D3 (mm) | 95 |
| H1 (mm) | 90 |
| h (mm) | 14 |
| Nett Weight (kg) | 40.5 |
