Description
Hafco Metalmaster
L468 Lathe Parting Blade — 26 × 2 × 110mm
Part No: L468 | Barcode: 9344195015045 | Brand: Hafco Metalmaster
T-section HSS parting blade sized for the L027 / L028 parting blocks. The 2mm kerf removes minimal material per cut while staying rigid in the slot, and the 26mm height carries the cut deep enough to part most stock the lathe will swing.
26mm Tall
2mm Kerf
110mm Long
Suits 26mm Blade
For Lathe Cut-Off Work
Key Features & Benefits
- 26mm blade slot — standard size matched to the L468 parting blade and most common HSS / insert blades.
- Hardened body — resists deformation under heavy parting loads where rigidity is everything.
- Squared shank — sits flat in the tool post without needing parallels or shimming.
- Locking screws on top — clamp the blade firmly without crushing or bowing it.
When to Use This Block
Parting blocks are the preferred way to hold a tall, thin parting blade rigid against the work. The blade hangs below the block, and the block sits in the tool post — this puts the cutting edge close to the toolpost and minimises chatter. Choose the tool height that matches your lathe’s tool-post centre height.
Authorised Australian Dealer — This product is sourced through Australian distributor Hafco Australia (Hare & Forbes Machineryhouse) and is backed by full Australian manufacturer warranty and local support.
Product Specifications
| Order Code | Type | Tool Height | Blade Size |
|---|---|---|---|
| L027 | Parting Block | 12mm | 26mm slot |
| L028 | Parting Block | 16mm | 26mm slot |
| L074 | Parting Tool Holder | 1/2″ (12.7mm) | 1/2″ HSS bit |
| L468 ★ | Parting Blade | — | 26 × 2 × 110mm |
★ You are viewing the highlighted variant. Match the parting block’s tool height to your lathe’s tool post centre height.
Browse our full range of metal lathes & tooling at Alltools Geelong.
