Excision MTGN Left Hand Turning Tool Holder — 16mm Shank (MTGNL-1616H16)
Part No: 781311616L | Barcode: 9341363315082 | ISO: MTGNL-1616H16
Excision MTGNL-1616H16 left-hand turning tool holder for the workshop lathe — a 16mm square-shank ISO-standard holder accepting TNMG160404 / TNMG160408 / DNMG1504-style indexable carbide inserts. Solid steel body with precision insert seat for repeatable tip location.
16mm Shank
Left Hand
ISO MTGN
Accepts TNMG160404
Steel Body
Key Features & Benefits
- ISO MTGN pattern — Standard insert pocket — accepts any compliant TNMG160404 / TNMG160408 / DNMG1504-style insert from Excision or other ISO suppliers.
- Left hand cutting — Built for facing operations and turning away from the chuck (left hand).
- 16mm square shank — Sized to drop straight into common 4-way and quick-change tool posts on hobby and light-industrial lathes.
- Suitable for low-power lathes — Geometry and rake suit smaller workshop machines without bogging the spindle.
- Australian supplier support — Backed by Excision Australia (Melbourne) — stocked locally with replacement parts available.
When to Use This MTGN Holder
Use Excision part 781311616L (MTGNL-1616H16) when you need a left-hand 16mm ISO-MTGN turning tool holder for indexable TNMG160404 / TNMG160408 / DNMG1504-style carbide inserts. Suits hobby and light-industrial lathes. Inserts sold separately.
Authorised Australian Dealer — This product is sourced directly from Excision Australia, an Australian engineering tools supplier based in Melbourne, and is backed by full Australian manufacturer warranty and local support.
Product Specifications
| Specification | Value |
|---|---|
| H | 16mm |
| B | 16mm |
| LF | 100mm |
| LH | 30mm |
| WF | 20mm |
| Brand | Excision |
| Series | MTGN |
| Holder ISO designation | MTGNL-1616H16 |
| Hand | Left hand |
| Shank size | 16mm square |
| Compatible inserts | TNMG160404 / TNMG160408 / DNMG1504-style |
| Insert pocket | ISO standard |
| Country | Australian-supplied (Excision, Melbourne) |
| Part number | 781311616L |
| Barcode | 9341363315082 |
