Harlingen 2.9mm HSS-Cobalt Jobber Drill Bit 10 Pack H-11-008-LC063-P

$25.00

Harlingen 2.9mm HSS-Co5% cobalt jobber drill bit, 10-pack. Straight-shank, fully-ground twist drill with a precision-ground point and gold finish for drilling stainless steel, steel and aluminium.

Availability: 1 in stock

Shipping & returns info
Barcode: 9346967113898Brand: HARLINGEN Categories: ,

Description

Harlingen

Harlingen 2.9mm HSS-Co5% Jobber Drill Bit — 10 Pack

Part No: H-11-008-LC063-P  |  Barcode: 9346967113898  |  Pack: 10 pieces

A 2.9mm cobalt (HSS-Co5%/M35) jobber-length twist drill supplied in a 10-piece trade pack. The 5% cobalt alloy and fully-ground point cut cleanly through stainless steel, alloy steel and aluminium where standard HSS bits overheat and blunt.

HSS-Co5% (M35)
5% Cobalt
2.9mm
Jobber Length
118° Point
Gold Finish
Fully Ground
10 Pack

Suitable For

Stainless Steel
Mild & Alloy Steel
Aluminium
Non-Ferrous Metals

Key Features & Benefits

  • HSS-Co5% (M35) cobalt steel — 5% cobalt is alloyed through the whole bit, not just coated on, so it keeps its edge and shrugs off the heat that dulls standard HSS in stainless and hardened steels.
  • 135° split point (3mm and up) — self-centring tip starts on the mark without a centre punch, reduces walking and needs far less thrust to bite.
  • Fully ground flutes — precision-ground geometry drills round, on-size holes and clears swarf cleanly for less heat build-up.
  • Gold surface finish — reduces friction and built-up edge so chips flow out of the flutes rather than welding to the cutting lips.
  • Jobber length, straight shank — standard DIN 338 proportions fit any keyed or keyless three-jaw drill chuck.
  • Trade multipack — supplied in economical 5 and 10-piece packs to keep your high-wear sizes stocked on the van or bench.

When to Use This Drill

Reach for the H-11-008-LC063-P (2.9mm, 10-pack) when you are drilling stainless steel, alloy and mild steel, or aluminium and the heat would cook an ordinary HSS bit. Its fully-ground point drills clean, accurate small-diameter holes, so you can start without a pilot hole. The cobalt content makes it the bit to choose for repetitive holes in tough or work-hardening metals where a standard drill would blunt after a handful of holes.
Pro Tip: Cobalt’s heat tolerance is wasted if the bit glazes the hole. On stainless, run a low RPM with firm, constant feed and a drop of cutting fluid — let it cut a continuous chip rather than rub, because rubbing work-hardens the surface and ruins both the hole and the cutting edge.
Authorised Australian Dealer — This Harlingen drill is sourced through our authorised Australian supplier Gamer and is backed by full Australian warranty and local support.

Product Specifications

Harlingen HSS-Co5% Straight-Shank Jobber Drill Range (1–13mm)
Part No. Diameter (mm) Point Pack Qty Barcode
H-11-008-LC025-P 1 118° point 10 9346967113843
H-11-008-LC035-P 1.5 118° point 10 9346967113850
H-11-008-LC037-P 1.6 118° point 10 9346967113867
H-11-008-LC045-P 2 118° point 10 9346967113874
H-11-008-LC055-P 2.5 118° point 10 9346967113881
H-11-008-LC063-P 2.9 118° point 10 9346967113898
H-11-008-LC065-P 3 135° split point 10 9346967113904
H-11-008-LC068-P 3.3 135° split point 10 9346967113911
H-11-008-LC075-P 4 135° split point 10 9346967113935
H-11-008-LC077-P 4.2 135° split point 10 9346967113942
H-11-008-LC080-P 4.5 135° split point 10 9346967113959
H-11-008-LC085-P 5 135° split point 10 9346967113966
H-11-008-LC088-P 5.3 135° split point 10 9346967113973
H-11-008-LC090-P 5.5 135° split point 10 9346967113980
H-11-008-LC095-P 6 135° split point 10 9346967113997
H-11-008-LC100-P 6.5 135° split point 10 9346967114000
H-11-008-LC103-P 6.8 135° split point 10 9346967114017
H-11-008-LC105-P 7 135° split point 10 9346967114024
H-11-008-LC110-P 7.5 135° split point 10 9346967114031
H-11-008-LC115-P 8 135° split point 10 9346967114048
H-11-008-LC120-P 8.5 135° split point 10 9346967114055
H-11-008-LC123-P 8.8 135° split point 5 9346967114062
H-11-008-LC125-P 9 135° split point 5 9346967114079
H-11-008-LC130-P 9.5 135° split point 5 9346967114086
H-11-008-LC135-P 10 135° split point 5 9346967114093
H-11-008-LC137-P 10.2 135° split point 5 9346967114109
H-11-008-LC140-P 10.5 135° split point 5 9346967114116
H-11-008-LC143-P 10.8 135° split point 5 9346967114123
H-11-008-LC145-P 11 135° split point 5 9346967114130
H-11-008-LC150-P 11.5 135° split point 5 9346967114147
H-11-008-LC155-P 12 135° split point 5 9346967114154
H-11-008-LC160-P 12.5 135° split point 5 9346967114161
H-11-008-LC163-P 12.8 135° split point 5 9346967114178
H-11-008-LC165-P 13 135° split point 5 9346967114185

★ You are viewing the highlighted variant. Other sizes in this Harlingen HSS-Co5% range are also available.

Brand: HarlingenSeries: HSS-Co5% Straight-Shank JobberDiameter: 2.9mmMaterial: HSS-Co5% (M35)Point: 118° pointShank: Straight (DIN 338)Pack Qty: 10
