Harlingen
Harlingen 4.5mm HSS-Co5% Jobber Drill Bit — 10 Pack
Part No: H-11-008-LC080-P | Barcode: 9346967113959 | Pack: 10 pieces
A 4.5mm cobalt (HSS-Co5%/M35) jobber-length twist drill supplied in a 10-piece trade pack. The 5% cobalt alloy and 135° split point cut cleanly through stainless steel, alloy steel and aluminium where standard HSS bits overheat and blunt.
HSS-Co5% (M35)
5% Cobalt
4.5mm
Jobber Length
135° Split Point
Gold Finish
Fully Ground
10 Pack
Suitable For
Stainless Steel
Mild & Alloy Steel
Aluminium
Non-Ferrous Metals
Key Features & Benefits
- HSS-Co5% (M35) cobalt steel — 5% cobalt is alloyed through the whole bit, not just coated on, so it keeps its edge and shrugs off the heat that dulls standard HSS in stainless and hardened steels.
- 135° split point (3mm and up) — self-centring tip starts on the mark without a centre punch, reduces walking and needs far less thrust to bite.
- Fully ground flutes — precision-ground geometry drills round, on-size holes and clears swarf cleanly for less heat build-up.
- Gold surface finish — reduces friction and built-up edge so chips flow out of the flutes rather than welding to the cutting lips.
- Jobber length, straight shank — standard DIN 338 proportions fit any keyed or keyless three-jaw drill chuck.
- Trade multipack — supplied in economical 5 and 10-piece packs to keep your high-wear sizes stocked on the van or bench.
When to Use This Drill
Reach for the H-11-008-LC080-P (4.5mm, 10-pack) when you are drilling stainless steel, alloy and mild steel, or aluminium and the heat would cook an ordinary HSS bit. Its 135° split point lets it bite straight onto the mark, so you can start without a pilot hole. The cobalt content makes it the bit to choose for repetitive holes in tough or work-hardening metals where a standard drill would blunt after a handful of holes.
Pro Tip: Cobalt’s heat tolerance is wasted if the bit glazes the hole. On stainless, run a low RPM with firm, constant feed and a drop of cutting fluid — let it cut a continuous chip rather than rub, because rubbing work-hardens the surface and ruins both the hole and the cutting edge.
Authorised Australian Dealer — This Harlingen drill is sourced through our authorised Australian supplier Gamer and is backed by full Australian warranty and local support.
Product Specifications
| Part No. | Diameter (mm) | Point | Pack Qty | Barcode |
|---|---|---|---|---|
| H-11-008-LC025-P | 1 | 118° point | 10 | 9346967113843 |
| H-11-008-LC035-P | 1.5 | 118° point | 10 | 9346967113850 |
| H-11-008-LC037-P | 1.6 | 118° point | 10 | 9346967113867 |
| H-11-008-LC045-P | 2 | 118° point | 10 | 9346967113874 |
| H-11-008-LC055-P | 2.5 | 118° point | 10 | 9346967113881 |
| H-11-008-LC063-P | 2.9 | 118° point | 10 | 9346967113898 |
| H-11-008-LC065-P | 3 | 135° split point | 10 | 9346967113904 |
| H-11-008-LC068-P | 3.3 | 135° split point | 10 | 9346967113911 |
| H-11-008-LC075-P | 4 | 135° split point | 10 | 9346967113935 |
| H-11-008-LC077-P | 4.2 | 135° split point | 10 | 9346967113942 |
| H-11-008-LC080-P ★ | 4.5 | 135° split point | 10 | 9346967113959 |
| H-11-008-LC085-P | 5 | 135° split point | 10 | 9346967113966 |
| H-11-008-LC088-P | 5.3 | 135° split point | 10 | 9346967113973 |
| H-11-008-LC090-P | 5.5 | 135° split point | 10 | 9346967113980 |
| H-11-008-LC095-P | 6 | 135° split point | 10 | 9346967113997 |
| H-11-008-LC100-P | 6.5 | 135° split point | 10 | 9346967114000 |
| H-11-008-LC103-P | 6.8 | 135° split point | 10 | 9346967114017 |
| H-11-008-LC105-P | 7 | 135° split point | 10 | 9346967114024 |
| H-11-008-LC110-P | 7.5 | 135° split point | 10 | 9346967114031 |
| H-11-008-LC115-P | 8 | 135° split point | 10 | 9346967114048 |
| H-11-008-LC120-P | 8.5 | 135° split point | 10 | 9346967114055 |
| H-11-008-LC123-P | 8.8 | 135° split point | 5 | 9346967114062 |
| H-11-008-LC125-P | 9 | 135° split point | 5 | 9346967114079 |
| H-11-008-LC130-P | 9.5 | 135° split point | 5 | 9346967114086 |
| H-11-008-LC135-P | 10 | 135° split point | 5 | 9346967114093 |
| H-11-008-LC137-P | 10.2 | 135° split point | 5 | 9346967114109 |
| H-11-008-LC140-P | 10.5 | 135° split point | 5 | 9346967114116 |
| H-11-008-LC143-P | 10.8 | 135° split point | 5 | 9346967114123 |
| H-11-008-LC145-P | 11 | 135° split point | 5 | 9346967114130 |
| H-11-008-LC150-P | 11.5 | 135° split point | 5 | 9346967114147 |
| H-11-008-LC155-P | 12 | 135° split point | 5 | 9346967114154 |
| H-11-008-LC160-P | 12.5 | 135° split point | 5 | 9346967114161 |
| H-11-008-LC163-P | 12.8 | 135° split point | 5 | 9346967114178 |
| H-11-008-LC165-P | 13 | 135° split point | 5 | 9346967114185 |
★ You are viewing the highlighted variant. Other sizes in this Harlingen HSS-Co5% range are also available.
