Description
Alpha SM6STRTP-B — SM6STRTP-B Drill Set available at Alltools Geelong. Shop our full SM6STRTP-B Drill Set range in Geelong.
Alpha
Alpha Onsite+ Step Tip Reduced Shank Drill Set — 6pc 15-20mm
Part No: SM6STRTP-B | Barcode: 9313601027262 | Series: Onsite+ Step Tip Reduced Shank
Reduced-shank step-tip drills extend the capacity of any 13mm chuck up to 20mm. Alpha’s Onsite+ versions add the patented step-tip — pilot and full-size hole in one plunge — plus black-oxide finish, 3-flat shank, and a bonus 250ml Alpha Liquid Gold cutting fluid in the Tuffbox Pro case.
6pc Set
15-20mm
Metric
M2 HSS
Step Tip Point
Alpha
Drills These Materials
Mild Steel
Stainless Steel
Aluminium Plate
Structural Section
Key Features & Benefits
- Patented step-tip — eliminates pilot drilling for 15-20mm holes — straight to size in one plunge.
- 12.7mm reduced shank with 3-flat grip — fits any 13mm chuck and resists slipping under heavy thrust.
- Black-oxide finish — holds cutting fluid on the flute and improves chip flow and heat dissipation.
- Bonus Alpha Liquid Gold cutting fluid — 250ml of premium cutting lubricant included — extends bit life on stainless and high-tensile steel.
- Tuffbox Pro storage — reinforced site case keeps the set organised on the truck or job.
When to Use This Set
Use this set when you need to drill 15-20mm holes in steel plate, structural section or stainless and you only have a 13mm-chuck drill. The step-tip + reduced shank combination saves the pilot-drill step and the chuck-swap that big bits normally need.
Drill Set Range — Mixed Brands
| Part No. | Brand | Pieces | Range | Construction |
|---|---|---|---|---|
| SM10ST | Alpha | 10pc | 4-12mm (1/4″ hex) | M2 HSS |
| SM15HPB | Alpha | 15pc | 2-6.5mm (1/4″ hex) | HSS-TiN |
| SM16ST | Alpha | 16pc | 4-13mm (1/4″ hex) | M2 HSS |
| SM17DTST | Alpha | 17pc | M3-M12 tap + 4-12mm drill | M2 HSS |
| SM23ST | Alpha | 23pc | 3-13mm (1/4″ hex) | M2 HSS |
| SM6STRTP-B ★ | Alpha | 6pc | 15, 16, 18, 19, 20mm (12.7mm shank) | M2 HSS |
| 12105SET25 | Excision | 25pc | 1.0-13.0mm × 0.5mm | HSS-Co (5% Cobalt) |
| D508 | Hafco | 5pc | No.1, 2, 3, 4, 5 | M2 HSS |
| 48894860 | Milwaukee | 19pc | 1.0-10.0mm × 0.5mm (1/4″ hex) | HSS-Titanium |
| 48894862 | Milwaukee | 29pc | 1.0-13.0mm × 0.5mm (1/4″ hex) | HSS-Titanium |
| 149060006 | P&N | 25pc | 2.0-13.0mm + 16.5mm countersink | HSS-Co (5% Cobalt) |
| 166044635 | P&N | 13pc | 1/16-1/4″ | M2 HSS |
| 166044639 | P&N | 13pc | 1.5-6.5mm + 3.3, 4.2mm | M2 HSS |
| 166044642 | P&N | 25pc | 1.0-13.0mm × 0.5mm | M2 HSS |
★ You are viewing the highlighted variant. Compare across the other brands above.
Browse our full range of drill bits at Alltools Geelong.
