Intech Tools
Intech Knurling Tool — 3-Way / Revolving Head
Part No: KTH1015 | Barcode: 9333608003465 | Brand: Intech Tools
The Intech KTH1015 is a revolving-head knurling tool that carries three pairs of wheels (typically fine, medium and coarse, or straight + diamond patterns). Rotate the head to switch knurl pattern without unbolting and re-mounting the tool — handy when you do mixed work or want to test which knurl looks best on a given diameter. The body is hardened steel and the wheels are user-replaceable when worn or when you want a different pattern.
3-Way / Revolving Head
Hardened Steel
Replaceable Wheels
For Engineering Lathes
Diamond / Straight Patterns
Key Features & Benefits
- 3-Way / Revolving Head configuration — chosen to match the way you load the spindle and the kind of parts you knurl most.
- Hardened steel body — stays rigid under the heavy radial load knurling generates.
- Replaceable knurl wheels — swap worn wheels or change pattern (diamond, straight, fine, coarse) without buying a new tool.
- Standard shank — mounts in any common lathe tool post.
- Forms knurls cold — the wheels press the pattern into the work; no chip-cutting, no swarf, just a clean grippy texture.
When to Use This Knurling Tool
Use the KTH1015 when you are putting a diamond or straight knurl onto round bar — handles, control knobs, press fits that need extra grip, or any part where you want a textured surface for the operator. Run the lathe slow (60-150 RPM is typical), use plenty of cutting oil, and feed in straight off the cross-slide rather than along the work.
Pro Tip: Calculate your starting diameter first. Knurling raises the surface — typically by about half the pitch of the wheel — so a 25mm finished knurl needs the work turned to roughly 24.7mm before you start. Measure the wheel pitch and back off accordingly, otherwise the diamonds will be flat-topped or the bar will be oversize.
Product Specifications
| Part No. | Type | Barcode |
|---|---|---|
| KTH1015 ★ | 3-Way / Revolving Head | 9333608003465 |
| KTH1017 | Double Wheel | 9333608003458 |
| KTH1019 | Single Wheel | 9333608003441 |
★ You are viewing the highlighted variant. Other types in this series are also available.
