Master Q
Master Q Threaded Tee — 25mm × 1/2" BSP (R215.025.012)
Part No: R215.025.012 | Barcode: 21696 | System: PE100 SDR11
Master Q R215.025.012 is a 25mm push-fit tee with a 1/2″ BSP female threaded branch, used to take a threaded tool or accessory outlet off a 25mm compressed-air main without breaking the run size. The two in-line ports are 25mm push-fit and the centre branch is a 1/2″ thread for a drop, valve or quick-coupler.
25mm run — 1/2" BSP F branch
Threaded Outlet
Push-Fit Run Ports
Tool Drop Take-Off
Demountable
Suitable For
Tool Drop Outlets
Quick-Coupler Stations
Mini Regulators
Workshop Reticulation
Key Features & Benefits
- 25mm run + 1/2" BSP female branch — keeps the 25mm main full-bore while providing a threaded tool outlet.
- Push-fit run ports — both in-line ports seal onto 25mm pipe with O-ring and collet.
- Threaded branch — screw in a quick-coupler, mini-regulator, blow gun or drop line.
- Demountable — serviceable and re-positionable on the run.
When to Use This Fitting
Use the R215.025.012 threaded tee to drop a 1/2" tool outlet off a 25mm air main — a quick-coupler station, blow-gun point or mini-regulator. For a full-bore 25mm branch use the equal tee instead. See the full Master Q range below.
Authorised Australian Supplier — This product is part of the Master Q compressed-air piping system, sourced from Master Q Australia with full local supplier support and warranty.
Master Q Compressed-Air Poly Piping System
| Part No. | Type | Size / Connection |
|---|---|---|
| 025PE100/10 | Poly Pipe (PE100 SDR11) | 25mm × 6m length |
| R210.025.025 | Straight Coupler | 25mm — 25mm |
| R213.025.025 | 90° Elbow | 25mm — 25mm |
| 727156307 | 45° Elbow | 25mm — 25mm |
| R214.025.000 | Equal Tee | 25mm — 25mm |
| 727206308 | Equal Tee | 32mm — 32mm |
| R221.025.000 | End Cap | 25mm |
| EP3 | End Cap | 32mm |
| C3 | Straight Coupler | 32mm — 32mm |
| M31-2520 | Female Threaded Connector | 25mm — 3/4″ BSP F |
| 727116307 | Female Threaded Elbow | 25mm — 3/4″ BSP F |
| R215.025.012 ★ | Threaded Tee | 25mm — 1/2″ BSP F |
| 158001920 | Wall Plate | 25mm — 3/4″ BSP F |
| PC25 | Pipe Clip | 25mm |
| PCC32 | Pipe Clip | 32mm |
| SV14-10 | Safety Relief Valve | 1/4″ BSP |
★ You are viewing the highlighted item. The Master Q poly piping range push-fits together — mix pipe, couplers, elbows, tees, threaded take-offs and clips to build your compressed-air reticulation.
