Description
Hafco Metalmaster
L0085 Carbide Turning Tool Set — 8mm Tool Height, 11 Piece
Part No: L0085 | Barcode: 9344195102172 | Brand: Hafco Metalmaster
Indexable carbide-insert lathe tool set with 11 tool holders sharing common ISO inserts. Each tool comes pre-loaded with one carbide insert; replacement insert pack is order code Re-grind on green-grit wheel. Supplied in a fitted case.
8mm Tool Height
11 Pieces
Carbide Insert Type
ISO Standard Inserts
Replacement: Re-grind on green-grit wheel
Fitted Case
Set Contents
5 × RH Turning
1 × LH Turning
2 × Boring Bars
Threading Tool
Parting Tool
Grooving Tool
Key Features & Benefits
- Indexable carbide inserts — rotate the insert when an edge dulls instead of regrinding HSS, saving setup time.
- Common insert across multiple holders — one box of replacements (Re-grind on green-grit wheel) keeps the whole set running.
- ISO-standard inserts — substitute any major brand (Kyocera, Sandvik, Mitsubishi, Korloy) when stocking up.
- 8mm square shank — matched to the 8mm centre-height tool post on Hafco bench lathes.
- Fitted storage case — keeps tools paired with their dedicated insert seats for fast set changes.
When to Use This Set
11-piece brazed-tip set for very small lathes (8mm centre height) — covers turning, threading, grooving and parting in one pack. Brazed tips re-grind on a green-grit wheel rather than indexing. Match the tool height to your lathe’s tool post — a 8mm centre-height post needs a 8mm shank tool with no shimming. Reorder replacement inserts as Re-grind on green-grit wheel.
Authorised Australian Dealer — This product is sourced through Australian distributor Hafco Australia (Hare & Forbes Machineryhouse) and is backed by full Australian manufacturer warranty and local support.
Product Specifications
| Order Code | Pieces | Tool Height | Replacement Insert |
|---|---|---|---|
| L0085 ★ | 11pc | 8mm | Brazed Carbide (non-indexable) |
| L0055 | 5pc | 10mm | L0615 |
| L450 | 3pc | 12mm | L062 |
| L451 | 3pc | 16mm | L0078 |
| L0077 | 7pc | 16mm | L0078 |
★ You are viewing the highlighted variant. Other tool-set sizes in the Hafco Metalmaster range are also available.
Browse our full range of metal lathes & tooling at Alltools Geelong.
